HORIBA OCMA-550 Oil Content Analyzer

HORIBA OCMA-550 Oil Content Analyzer – High-Precision Oil Measurement

The HORIBA OCMA-550 is an advanced oil content analyzer designed for rapid and accurate oil measurement in wastewater monitoring, environmental analysis, and quality control applications. Utilizing a solvent extraction and non-dispersive infrared absorption analysis method, the OCMA-550 ensures precise detection of oil content without complex evaporation processes.

Key Features:

• One-Touch Automatic Measurement: Provides quick results in approximately 3 minutes.
• Low-Boiling Point Oil Detection: Unlike n-hexane methods, it prevents volatilization of light oils like gasoline.
• Direct Oil Concentration Display: Displays oil content in mg/L without requiring weight-based calculations.
• Environmentally Friendly Solvent: Uses S-316 extraction solvent, compliant with global environmental regulations.
• High Measurement Accuracy:
  • Measurement Range: 0 mg/L to 200 mg/L.
  • Resolution: 0.1 mg/L for values up to 99.9 mg/L, 1 mg/L for values from 100 to 200 mg/L.
  • Repeatability: ±0.4 mg/L for values up to 9.9 mg/L, ±2 mg/L from 10 to 99.9 mg/L, and ±4 mg/L for values above 100 mg/L.
• User-Friendly Display: 3.5-inch color LCD screen for easy data viewing.
• Data Storage & Export: Stores up to 300 measurement data sets and supports USB data export.
• Compact & Lightweight: Dimensions: 195 (H) × 253 (W) × 293 (D) mm, Weight: Approx. 5 kg.
• Compliant with ASTM D7066-4 Standards for oil content analysis.

Applications:

• Wastewater Monitoring: Ensures compliance with industrial discharge regulations.
• Oil Spill & Contamination Testing: Ideal for marine, industrial, and environmental assessments.
• Manufacturing & Quality Control: Monitors oil contamination in components and materials.
• Factory Drainage Monitoring: Supports efficient environmental water management.

The OCMA-550 simplifies oil measurement with a single-button operation, making it the perfect choice for industries requiring fast, accurate, and cost-effective oil content analysis.
